GroundLock Extreme Interlocking ESD Tile

Colorway
Medium Gray
Usage
Commercial
Delivery
check-mark
FedEx Priority Overnight
Price Range
$$$$$
Sku
5-0401
Description
GroundLock Extreme Interlocking Tile is installed quickly and easily without adhesive. It can be installed over any subfloor, including problem concrete and old, damaged floors, and does not require moisture testing. A layer of fiberglass sandwiched between material layers ensures dimensional stability, with no lifting or doming. GroundLock Extreme can handle extremely heavy loads and is easy to clean with soap and water and a mop or auto-scrubber. GroundLock Extreme can be installed with minimal disruption in 24/7 operational spaces, and is easy to lift and carry away, making it an ideal floor for leased or temporary spaces. Meets all ANSI/ESD and ASTM parameters for static control, is FloorScore certified, and constructed with 50% recycled materials.
Materials
Flooring/Static Control Flooring
Collection Name
Interlocking Tile
Sample Size
6 in x 6 in
Size
25 in x 25 in (635 mm)
Warranty
Lifetime Warranty
Content
Vinyl
Construction
Solid Vinyl
Format
Modular
Total Weight
1.89 lbs/ft²
Overall Thickness
6 mm
Wear Layer Thickness
2 mm
No-wax for life. Neutral cleaner and water maintenance only. Refer to Maintenance Guidelines PDF for more details
Indoor & Outdoor
Indoor
Applications
Flooring, Electrostatic Dissipative Flooring
Installation
Designed for quick, hassle-free installation, this floor is easily disassembled and moved to a different space or location. GroundLock EXTREME interlocking tiles can be installed by anyone—with or without experience. If the space is redeployed, it’s no big deal.As the floor is completely reusable, GroundLock Extreme saves time and money.Installable over any sub-floor, with no disruption and no permanent commitment, GroundLock Extreme is an ideal solution for leased spaces, concrete slabs with vapor issues, occupied spaces, operational cleanrooms, and spaces requiring fast installation.Unlike most tile, our GroundLock Extreme ESD vinyl tiles are installed without adhesives and are dimensionally stable (without full adhesion). GroundLock Extreme tiles come in interlocking tiles or as cut, flat-edge tiles* for one-to-one installation over raised access floor panels. Refer to Installation Instructions PDF for more details
Slip Resistance
ASTM D2047 Coefficient of Friction - 0.80 (Dry) / 0.82 (Wet)
Emissions
ISO 16000-6 TVOC After 28 Days - < 10 Вµg/mВі
Hardness
ASTM D2240 Indentation Hardness (Type A Shore Durometer) - 95
Climate Impact
LEED Compliant
Human Health Impact
CDPH / CHPS 01350 Compliant, Low Emitting/Low VOC, Phthalates free, REACH Compliant, SCS Global FloorScore Certified
LEED
May contribute to LEED Credits
VOC Emissions Testing Methodology
CDPH / CHPS 01350 Compliant

StaticWorx

Our diverse line of ESD floors gives specifiers an attractive anti-static option for almost any space. All StaticWorx floors are FloorScore or Green Guard certified, warrantied for static control, and made in the US or EU, ensuring a reliable supply chain. We also offer a well-regarded CEU workshop.
