Pixa Dimensional Terrazzo Sequence Curry 20 with Aggregate and Fiber

Intended for commercial project specification only.
Colorway
Curry 20 - Aggregate + Fiber
Usage
Commercial
Delivery
Ships in 1–5+ Days From Brand
Price Range
$$$$
Sku
051251063110111100
Description
Light-conducting channels in PIXA create a unique, light-filtering screen. It also is available as dimensional slabs and panels punctuated with light pillars that pierce the terrazzo substrate. A secondary, "floating" surface comes to life with dynamic visual output created by light, shadow, movement and colors.
Materials
Masonry & Stone/Terrazzo; Surfaces/Terrazzo
Collection Name
Pixa Dimensional
Sample Size
4 in x 4 in
Size
Highly customizable. Can be colored, patterned, shaped, mounted, or etched to specification. Add an inlay to create custom looks with immense design opportunity. Light terminals are available in various shapes, sizes and at varying heights from surface
Series Name
Light Filtering
Custom Capabilities
Highly customizable. Can be colored, patterned, shaped, mounted, or etched to specification. Add an inlay to create custom looks with immense design opportunity. Light terminals are available in various shapes, sizes and at varying heights from surface
Availability
Made to Order / Special Order
Lead Time
Ranges from 2-6 weeks for flat panels and 6-10 weeeks for complex solutions
Country of Origin
United States
State of Origin
Michigan
City of Origin
Ypsilanti
Warranty
1 Year
Content
Micro-concrete matrix with light conducting channels (available with or without aggregate)
Finish
Polished, Honed, or Sandblasted. Sealers include Penetrating (factory standard StoneTech "Bulletproof"), Ultra Matte, Ultra Semigloss. When exposure to food or drink is expected, an Ultra sealer is recommended
Construction
Custom cast to approved shop drawing specifications
Format
Modular, Panel / Sheet, Slab
Total Weight
Between 9 - 15lbs/sqft depending on thickness selection
Overall Thickness
0.625in, 0.875in, and 1.25in
Edge / End
Factory edge, polished edge, eased edge, chamfered edge, radiused edge, bullnose edge, mitered edge, drop down, or drop down radiused edge
Maintenance
Wipe down regularly with a microfiber cloth in conjunction with water/dish soap solution, StoneTech&apos
Indoor & Outdoor
Indoor, Outdoor
Applications
Screening, feature walls, signage, video screens, vertical and horizontal surfacing
Installation
Installation method varies by application. It is recommended that installation be completed by a trained professional. See Installation Guide for additional infromation.
Flammability
ASTM E84 Class A. UL 94 Tested. Considered not flammable
Weather Resistance
ASTM C1026 Freeze Thaw Resistance Tested. No visible evidence of change after 15 cycles
Water Absorption
ASTM C97 Tested. &lt
Emissions
CAL 01350 Tested. No VOC emissions during manufacture or life cycle of product
Climate Impact
Environmental Product Declaration (EPD), LEED Compliant
Human Health Impact
CARB Compliant, CDPH / CHPS 01350 Compliant, Health Product Declaration (HPD), Low Emitting/Low VOC
LEED
May contribute to LEED credits. See LEED documentation for additional details.
Environmental Product Declaration
Product-Specific EPD
EPD Expiration Date
Jan 8, 2023
Global Warming Potential (GWP)
170
GWP Functional Unit
kg CO2eq
Ingredient Disclosure
Health Product Declaration (HPD)
Disclosure/ Certification Expiration Date
Feb 21, 2021
Disclosure Level
1000 ppm
Post-Consumer Recycled Content Percentage
0.06
Manufacturing Location
United States
VOC Emissions Testing Certificate
Intertek Clean Air
VOC Emissions Testing Certificate Expiration Date
May 23, 2025
VOC Emissions Testing Methodology
CDPH / CHPS 01350 Compliant
