Solid - Interior Compact Laminate Panel

0080
Colorway
Black
Usage
Commercial, Residential
Delivery
Ships in 1–5+ Days From Brand
Price Range
$$$
Sku
FMX-0080-FH
Materials
Surfaces/Laminate
Collection Name
Max Compact Interior
Sample Size
4.75 in x 4.75 in
Size
Available in Fine Hammered (FH) finish: 84.25in x 41.75in (size code TK), 110.25in x 51.1875in (size code GR), 110.25in x 73in (size code SP), 161.375in x 51.1875in (size code JU), 161.375in x 73in (size code XL), 144.5 x 64.1875in (size code OF). Available in Matte (MT) finish: 110.25in x 51.1875in (size code GR). Not all sizes are available in all colors. Inquire with brand rep for additional information
Custom Capabilities
FunderMax offers CNC controlled processing and panel cutting. Specify anything from intricate milling to simple cutouts for mounting purposes
Availability
Limited Stock, Made to Order / Special Order, Stocked in North America
Country of Origin
Austria
Warranty
10 years
Content
A layered kraft paper core impregnated with phenolic resin and double-sided decorative surface layers of melamine-impregnated paper
Finish
Fine Hammered (FH) or Matte (MT)
Construction
Pressed under high pressure and temperature
Format
Panel / Sheet
Total Weight
13.5 kg/m2
Overall Thickness
2mm-20mm
Edge / End
Panels contain a black core that is visible at the edge. It is not necessary to seal edges, even after cutting and sanding
Clean with hot water and a soft sponge, cloth, or brush. Common household cleaners, organic solvents, and commercially available disinfectants can also be used when necessary. Avoid abrasive cleaning products
Indoor & Outdoor
Indoor
Applications
Used for a variety of interior applications including wall, ceiling, or column cladding, furniture, lockers, cabinets, batroom partitions, railing infill panels, and laboratory work surfaces. Double-sided panels are also useful as machine tables, molding boards, and other non-decorative applications
Installation
Installation guidance is application-dependent. Process similar to a hardwood – cut and drill on a CNC router, milling machine, or panel saw. Field cuts can be done with common hand tools (circular saws, compound miter saws, etc.). Several unique fastening systems are available. Refer to the attached Tech Guide for additional information
Manufacturer Notes
As a standard, panels come double-sided with a black core
Flammability
EN 13501-1 tested. Result of D-s2, d0. ASTM E84 tested. Results between Class A & Class B depending on material thickness and core selection. Tested in accordance with CAN/ULC S102-18, Standard Method of Test for Surface Burning Characteristics of Building Materials and Assemblies
Classification
Manufactured to standard EN 438
Abrasion / Wear Resistance
EN 438-2:2016, Point 10 (resistance to stress abrasion) tested. Result of ≥ 150 U. EN 438-2:2016, Point 25 (resistance against scratching) tested. Result of ≥ 4 N
Impact Resistance
EN 438-2:2016, Point 21 (falling ball impact) tested. Result of 8mm.
Lightfastness
EN 438-2:2016, Point 27 (lightfastness) tested. Level ≥ 4 results
Weather Resistance
EN 438-2:2016, Point 16 (resistance to dry heat at 160°C) tested. Result of ≥ 4°
Water Absorption
Panels will expand and contract due to environmental moisture conditions
Chemical Resistance
Refer to attached chemical resistance testing documentation
Emissions
Classified as a low-emitting material
Climate Impact
Forest Stewardship Council (FSC) Certified, ISO 14001, LEED Compliant, Programme for the Endorsement of Forest (PEFC) Certified
Human Health Impact
CARB Compliant, CDPH / CHPS 01350 Compliant, Formaldehyde Free, Low Emitting/Low VOC, UL GREENGUARD, UL GREENGUARD GOLD
LEED
May contribute to LEED credits

Fundermax

Fundermax produces sustainable, high-pressure laminate panels, also known as phenolic panels, for exterior, interior and laboratory surfaces that are customizable, durable and easy to install. We hold ISO certifications in several international standards and aim to understand and respect the needs of architects, designers, contractors and building owners.
