Flannery, Inc.

Siding Inside Corner Reveal

Colorway
Clear Anodized
Usage
Commercial, Residential
Delivery
check-mark
FedEx Priority Overnight
Price Range
$$$
Sku
SIC 625-100
Available Sizes:
5/8 in D x 1 in W
arrow-up
Description
Flannery’s Siding Inside Corner Reveal creates an aesthetic termination reveal between two Panels that meet at an inside 90° corner. The Siding Inside Corner Reveal is an attractive alternative to simply butting two panels against one another at an inside corner.
Architectural
Moulding & Trim/Metal Profiles
Collection Name
Panel Trim
Size
"A" Dimension = Depth ; "B" Dimension = Width
Series Name
Inside Corner
Custom Capabilities
Paint colors can be customized
Availability
Typically Stocked
Lead Time
1 Week
Order Increments
Flannery's Aluminum Trims are shipped and stocked in 10-foot lengths unless otherwise specified
Country of Origin
United States
State of Origin
Texas
Product Details
  • Flannery's Siding Trims are standard extruded aluminum alloy 6063 T5 and have a typical 0.050" nominal wall thickness.
  • Aluminum Siding Trims are aesthetic trims not intended to hold or support the weight of any panel system.
  • Please consult a structural engineer when considering the use of Flannery Furring Strips or Z-Fur Strips in a rainscreen system
Content
Aluminum
Format
Modular
Width
1 in
Indoor & Outdoor
Indoor, Outdoor
Applications
Ceiling
Installation
Installation of Siding Trims must be in accordance with the Siding Manufacturer's Instructions
Manufacturer Notes
Flannery's Siding Trims are standard extruded aluminum alloy 6063 T5 and have a typical .050" nominal wall thickness. Aluminum Siding Trims are aesthetic trims not intended to hold or support the weight of any panel system. Please consult a structural engineer when considering the use of Flannery Furring Strips or Z-Fur Strips in a rainscreen system. It is important for the installer to be aware of certain restrictions when installing Aluminum Siding Trims on an exterior wall. Certain trims are designed specifically for vertical or horizontal installation to allow for the proper movement of moisture around the paneling. Trim installed improperly could lead to moisture intrusion or a poor wall design. Please refer to flannerytrim.com for a more comprehensive installation guide of exterior panel trims
Climate Impact
100% Recyclable
LCA Optimization Plan
No
75% of Ingredients Disclosed
No
Third-Party Bio-Based Certification
No
End-of-Life Options
100% Recyclable
RoHS Compliance
No
Electronic Components in Product
No

Flannery, Inc.

Flannery is a family-owned and operated manufacturer of a wide range of aluminum trim products designed to complement interior and exterior walls and ceilings. Flannery is pleased to provide technical assistance and service to enable any builder, architect, or owner to achieve their design goals.
