Feeney

Resin Panel Infill (3form)

Colorway
Ting Ting
Usage
Commercial, Residential
Delivery
check-mark
FedEx Priority Overnight
Price Range
$
Sku
FDRR5TT
Description
Alternative infills for railings are a growing trend. The ease of installation and unlimited design potential make them a great way to add to the look and feel of any space. Resin panels are composed of 1/4-inch-thick resin panels with organic embedded materials and are suitable for indoor applications only.
Materials
Paneling/Resin Paneling; Resin/Decorative Panels
Collection Name
DesignRail®
Sample Size
4 in x 4 in
Size
32in or 42in H x 5ft W
Availability
Made to Order / Special Order
Lead Time
4-6 weeks
Country of Origin
United States
State of Origin
Nebraska
City of Origin
Tekamah
Warranty
10 year limited warranty
Content
PETG and Copolyester Resins
Finish
Sandstone Finish (Light Texture)
Construction
Interlayers are laminated between two PETG resin panels, fusing them into a solid sheet. Sheets are peel-coated with a protective film and trimmed to size
Overall Thickness
1/4"
Maintenance
Wipe with a soft cloth and a solution of mild soap and/or liquid detergent in water. Rinse thoroughly. Never use scrapers or squeegees and avoid strong solvents
Indoor & Outdoor
Indoor
Flammability
Dependent on material thickness. 0.0625in - 0.1875in and 1in receive an ASTM E84 Class A rating. Remaining thickness options receive a Class B rating. Passes ASTM D2843, D635, and D1929, UL 94 and NFPA 286. Refer to flame spec for additional information
Impact Resistance
ASTM D3763 Tested. Refer to Technical Spec for additional information.
Lightfastness
ASTM G155 Tested
Water Absorption
ASTM D570 Tested. Between 0.1% - 0.2% depending on material thickness
Acoustics
ASTM E90 Tested. Results are dependent on material thickness. 0.125in = 25 STC value, 0.1875in = 29 STC value, 0.25in = 31 STC value, 0.375in = 34 STC value, 0.5in = 34 STC value, 1in = 39 STC value
Hardness
ASTM D785/Rockwell Hardness Tested. Between 115 - 117 depending on material thickness.
Climate Impact
Manufacturer Take-Back Program, Recycled Content - Post-Consumer, ISO 14001, LEED Compliant, Recycled Content
Human Health Impact
CARB Compliant, Low Emitting/Low VOC, UL GREENGUARD
LEED
May contribute to LEED credits

Feeney

For more than 70 years, Feeney® has led the industry with innovative and easy-to-install architectural products for residential and commercial use. Our design-centric products include CableRail stainless steel railing assemblies, Quick-Connect® cable fittings, DesignRail® railing systems and more.
