American Biltrite

ABPURE Imagine Hammered Rubber Tile

15
Colorway
Snowstorm
Usage
Commercial
Delivery
check-mark
FedEx Priority Overnight
Price Range
$$$
Sku
ABM-15-53E
Description
ABPURE Nfuse Tiles are a collection of homogeneous rubber flooring featuring solid colors or chip designs (Imagine) and available in smooth, round, and slate profiles. It is PVC-free and phthalate-free and has obtained the Declare Red List Free certification. It is an occupancy ready tile collection that does not require waxing for the lifetime of the floor and provides the purest colors that won't yellow or fade with a 10 year color fastness warranty per ASTM F1515.
Materials
Flooring/Rubber Flooring; Flooring/PVC-Free Flooring
Collection Name
ABPURE® Nfuse
Size
17 13/16in x 17 13/16in (452mm x 452mm), 35 11/16in x 35 11/16in (905mm x 905mm)
Custom Capabilities
Custom color, logo, and design capabilities available. Minimum order required. Contact your sales rep for details
Availability
Typically Stocked, Stocked in North America
Lead Time
4-6 weeks standard but may vary depending on quantities and project. Contact your sales rep for details
Order Increments
17 13/16in Tile - 44.065 sqft (4.094 sqm) Coverage, 35 11/16in Tile - 8.844 sqft (0.822 sqm) Coverage
Country of Origin
Canada
Warranty
10 Year Limited Wear Warranty
Construction
Homgeneous Rubber Tile
Content
Rubber
Finish
Nfuse Technology
Format
Modular
Overall Thickness
0.118in (3mm)
Occupancy ready, no wax for life
Indoor & Outdoor
Indoor
Applications
Flooring (Education/Institutional, Healthcare, Hospitality, Light Commercial/Light Industrial, Retail, Transportation/Public Venues)
Installation
Adhesive. Refer to Installation attachment for details
Manufacturer Notes
Please contact your American Biltrite sales rep for the most up to date technical documents
Flammability
ASTM E648 Critical Radiant Flux (W/cm2) ≥ 0.45; ASTM E662 Smoke Density ≤ 450
ADA
Meets ADA requirements for slip resistance
Classification
ASTM F1344 - Type 1, A or B (Homogeneous)
Abrasion / Wear Resistance
Passes ASTM D3389 - Abrasion Resistance (H-18,500 g @ 1,000 cycles)
Lightfastness
ASTM F1515 - ΔE ≤ 8.0
Slip Resistance
ASTM D2047 Static Coefficient of Friction (leather) ≥ 0.5
Chemical Resistance
Exceeds ASTM F925
Antimicrobial Testing
ASTM G21 - Pass (28 days)
Acoustics
ASTM E989 / E492 Sound Absorption (with a suspended ceiling) - IIC 59
Climate Impact
Recycled Content - Pre-Consumer, Environmental Product Declaration (EPD), ISO 14001, LEED Compliant, PVC free, Recycled Content
Human Health Impact
CARB Compliant, CDPH / CHPS 01350 Compliant, Declare Label - LBC Compliant, Declare Label - LBC Red List Approved, Declare Label - Red List Free, Low Emitting/Low VOC, Phthalates free, REACH Compliant, SCS Global FloorScore Certified
LEED
May contribute to LEED credits.
Organizational Commitments
ISO 14001
Environmental Product Declaration
Product-Specific EPD
EPD Expiration Date
Jan 1, 2025
Global Warming Potential (GWP)
17.100
GWP Functional Unit
kg CO2eq
LCA Optimization Plan
No
75% of Ingredients Disclosed
No
Post-Industrial Recycled Content Percentage
10.000
Third-Party Bio-Based Certification
No
Material Health Certifications
Declare Label - LBC Red List Approved, Declare Label - Red List Free
VOC Emissions Testing Methodology
CDPH / CHPS 01350 Compliant
RoHS Compliance
No
Electronic Components in Product
No
