Ledalite by Signify

Trugroove Micro Suspended Luminaire with Louver

Usage
Commercial
Delivery
Ships in 1–5+ Days From Brand
Sku
TM05L935NMCFF20Q2002DE1NNNB-sample
Description
TruGroove suspended micro louver drives performance beyond the edge. Innovative optics deliver exceptional uniformity and wide-row spacing from a 1.75-inch aperture, continuous line of light. Unique Quad Optic louver cells offer a wide range of options from graze to stack to asymmetric wall wash, exceeding the demands of the most challenging spaces. TruGroove suspended micro louver includes AccuRender technology for the highest color quality at the highest efficacy.
Furniture Fixtures And Equipment
Lighting/Ceiling Lights; Lighting/Architectural Lighting
Custom Capabilities
TruGroove can also be specified in any custom color upon request for a one-time setup charge
Availability
Typically Stocked, Quick Ship, Made to Order / Special Order
Lead Time
10-day QuickShip available for most configurations upon request
Warranty
5-Year Limited Warranty
Product Details
    MesoOptics producing true batwing distribution.
  • AccuRender CRI 90 available in 5 color temperatures and tunable white.
  • Multiple up/down lumen package options.
  • Symmetric, asymmetric, direct, indirect, and direct/indirect distribution options.
  • Interact Pro scalable sensors.
  • Lens/louver combinations available.
Lamping
LED
Finish
High quality powder coated, available in standard Matte White, Black, Titanium Silver or Graphite Grey
Total Weight
Maximum 3.8/ft (suspended), 10lb (2ft x 2ft suspended corner)
LEDs have been tested by the manufacturer in accordance with IESNA LM-80-15. At an ambient temperature of 25°C, the LED lumen maintenance expectation according to IES TM-21-11 is: L80 (10k) > 60,000 hours (Reported methodology)
Indoor & Outdoor
Indoor
Applications
Office, Retail, Education, Hospitality, Healthcare, Airport
Installation
Suspended: Variable sling mount allows ± 5" of horizontal adjustment from joint or end. Aircraft cable and tamper-resistant gripper provide unlimited vertical adjustment and are independently tested to stringent safety standards.
Climate Impact
DLC Qualified
Human Health Impact
WELL Compliant

Ledalite by Signify

Ledalite offers a wide selection of architectural lighting products that are made-to-order or customized, with billions of configuration possibilities. Specifiers have relied on Ledalite’s performance, quality, and architectural aesthetic to enhance their commercial, retail, and educational spaces.
