Starphire

Starphire

Ultra-Clear

Glass sample from Vitro Architectural Glass: Starphire: Ultra-Clear. MFR SKU: ST-19 1153564
Starphire

Ultra-Clear

  • Materials: Glass, Architectural Glass
  • SKU: ST-19
  • Residential Use
  • Commercial Use
  • Materials: Glass, Architectural Glass
  • SKU: ST-19
  • Residential Use
  • Commercial Use
  • Availability: Typically Stocked, Stocked in North America
  • Country of Origin: United States
  • Material Origin: Manufactured in Carlisle, PA; Wichita Falls, TX; or Fresno, CA. Company is headquartered in Nueva Leon, Mexico.
  • Content: Low-iron float glass
  • Finish: Uncoated
  • Custom Finishes: Starphire® is a useful substrate for ceramic frit and vacuum sputtered coatings. Available with AviProtek® or Solarban®. Opacifiers can be employed without a green hue and can be combined with OPACI-COAT-300®. Use Clarvista™ for shower glass enclosu
  • Construction: Float glass process
  • Format: Panel / Sheet
  • Edge / End: Azure blue edge. The color gradually changes according to the length of the glass.
  • Indoor & Outdoor: Indoor, Outdoor
  • Applications: For interior or exterior applications. Curtainwall glass applications and facades, such as vision glazings and spandrel glass are appropriate. Commonly used for windows, glass doors, side lites, dividing walls, wall coverings, skylites, clerestories, handrails and balustrades, shelves, shower enclosures, tabletops, backsplashes, and partitions. Also ideal for decorative applications, such as dichroic, acid-etched, digitally printed, and bird-friendly glasses. Heavy safety and security glass options are suitable for building entrances, reception areas, protective windows, storefronts, jewlery displays, museum cases, zoo enclosures, and marine aquariums. Many of these applications require processing into coated, heat-treated, or laminated glass products and/or assembled into multi-pane insulating glass units (IGUs) specified by architects, glazing contractors, and other building professionals. The glass also may be used for a limited range of industrial applications, including solar power collection and others.
  • Installation: Can be cut, edge polished, drilled, heat treated, and laminated.
  • Manufacturer Notes: 87% less green than ordinary clear glass. Glass samples should be evaluated in natural daylight. Artificial light may emit wavelengths that can skew perception of glass color. Perceived glass color can be influenced by sample size. The color of a 12in x 12in sample may not appear the same as a 4ft x 10ft glazed unit of the identical glass.
  • Classification: Follows NSF GANA Product Category Rule (PCR) for Flat Glass - UNCPC 3711.
  • Tensile Strength: 41.4 Mpa / 6,000 psi
  • Flexural Strength: Modulus of Elasticity result of 73.1 GPa / 10,600,000 psi
  • Hardness: Koop Hardnes Number (indention) of 470 kgf/sqmm
  • Environmental Benefits: Using energy-efficient architectural glass can result in reduced building impacts. Certain manufacturing sites employ water reclamation operations that divert treated non-potable wastewater from municipal wastewater treatment facilities. Manufacturing sites are equipped with extensive systems to recover and store discarded or scrap glass (known as cullet). This valuable feedstock reduces procurement of virgin materials and the amount of energy consumed during the glass-melting process. Greater than 99% of unused glass is reutilized in production. Products arrive in a special steel packing that is returned to Vitro facilities after delivery. The lifespan of the product is defined as 30 years per NSF GANA Product Category Rule (PCR) for Flat Glass - UNCPC 3711.
  • Social Impacts: Socially Responsible Company Distinction from CEMEFI (Centro Mexicano para la Filantropía).
  • Certificates & Standards: Cradle to Cradle™ and Material Heath certified for products in the United States. Environmental Product Declarations (EPD) are available for US-produced goods. Manufacturing sites are certified to ISO 9001:Quality Management System. Many sites also have ISO 14001:2004 certification, and others are in the process of being re-certified under the updated ISO 14001-2015 standard.
  • LEED: May contribute toward LEED credits
  • Recycling Notes: Glass is a technical nutrient with multiple options for reuse after deconstruction. Suitable as an aggregate in concrete and asphalt applications, and when finely ground, recycled float glass also can be used as a partial replacement for cement in concrete. Broken glass (cullet) also is a valuable feedstock in the production of glass, as it greatly reduces demand for virgin materials and reduces the melting temperature for batch materials. Vitro encourages recycling of all glass products when reuse is not plausible.
  • Post-Industrial Recycled Content Percentage: Cullet typically comprises between 10%- 20% of the final manufactured glass product.

About
Vitro Architectural Glass.

With Vitro Architectural Glass (formerly PPG Glass) now operating as a global company, architects can expect accelerated research and development efforts, in addition to greater glass capacity, in years to come.

Now operating as a global glass company, architects can expect accelerated research and development efforts in addition to greater glass capacity from Vitro Glass in years to come.

Our website offers one of the industry’s most comprehensive portals for glass research, product selection and specification. Visit VitroGlazings.com/tools to search for and compare products, configure custom insulating glass units and generate three-part specifications while utilizing the full International Glazing Database and more – all without a login.

Vitro Environmental Glass also is committed to environmental sustainability. Throughout its history as PPG Flat Glass, Vitro Architectural Glass raised the bar, becoming the first company to become Cradle to Cradle Certified™ for its entire collection of architectural glasses and the first North American manufacturer to publish third-party verified Environmental Product Declarations for its entire collection of flat glass and processed glass products. Vitro Architectural Glass products also assist architects to achieve LEED certification for their projects in nine credit categories under LEED v4, the most recent version of the rating system.
